Introduction

• The JET-5709AA DDR5U-SODDR5 Adapter is designed for testing of memory module maker.
•  It is used to protect the Memory module socket during testing.
•  For SODDR5 module testing, user needs plug the JET-5709AA into tested machine (such as motherboard or SODDR5 testing equipment) firstly. And plug the Module into socket of JET-5709AA during module testing.

Feature

• Compatibility：Compliant with JEDEC Specification MO-337A.
• Lifespan：Normal operation is without human wrong insertion. SODDR5 socket lifespan able to over 600 times is used for memory module maker.
•  Frequency over 4800 MHz.
