U.2 (SFF.8639) to PCIe I/F SSD adapter with 2.5" enclosure

Write a Review

Contact us at support@mfactors.com for more info

Product Overview

  • 4-Layer PCB designed
  • Built-in SFF-8639 plug connector
  • Built-in M.2 (NGFF) M-key receptacle connector
  • LED2 ON indicate M.2/PCI-e 4 Lanes device power OK
  • LED3 indicate active status
  • Supports CLKREQ# functions to implement PCIe port circuit power on/off
  • PCI Express Base Specification Rev 3.0
  • SFF 8639 Enterprise SSD Form Factor Version 1.0a
  • PCI Express Card Electro-Mechanical* (CEM) Specification Rev 2.0
  • PCI Express M.2 Spec. Revision 0.7, Version 1.0
  • NVM Express 1.2a
  • PWM synchronous buck converter Power IC

※ 3.3V, 4A maximum output current
※ Short circuit protection
※ In-rush current suppression
※ Thermal shutdown protection
※ ESD HBM (Human Body Mode)/2KV
※ ESD CDM (Charged Device Model) /500V
